BM Series

Print
Description

Coming Soon
Main Features
Coming Soon

 Main Specifications

Sales Model Unit BM 2740 BM 2740M BM 2740P
Effective Width Between Columns mm (inch) 2740 (107.87) 2700 (106.3) 2740 (107.87)
X-axis Travel
(Table Longitudinal)
mm (inch) 4000 (157.48) 4000 (157.48) 4000 (157.48)
Table Size mmxmm (inchxinch) 4000 x 2500 (157.48 x 98.43) 4000 x 2500 (157.48 x 98.43) 4000 x 2500 (157.48 x 98.43)
Spindle Speed r/min 10000 12000 12000
Max. Spindle Moter Power Power 30 (40.2) 30 (40.2) 22 (29.5)
Tool Shank - CAT 50 CAT 50 CAT 40
NC System - FANUC FANUC FANUC
